TECAPEEK® GF30 natural – PEEK 30% GLASS FIBER REINFORCED

TECAPEEK® GF30 natural is a special 30% glass filled PEEK modification where, in comparison to unfilled PEEK, this glass fiber reinforced material exhibits increased mechanical strength and high rigidity. Furthermore, improved creep strength and dimensional stability are achieved by this glass filled PEEK. These properties make this material suitable for use in parts which are exposed to high static loads over long periods in high temperature conditions. As glass fibers tend in some cases to have a marked abrasive effect on mating surfaces, TECAPEEK GF30 is less suitable for bearing or wear applications. TECAPEEK GF30 offers excellent chemical resistance, is insoluble in all common solvents, and exhibits superior resistance to high doses of gamma radiation. As with all PEEK grades, PEEK GF30 combines high thermal stability with minimal thermal expansion and very low moisture absorption.

Advantages of TECAPEEK® GF30 natural:

  • Very good chemical resistance
  • Good heat deflection temperature
  • Inherent flame resistance
  • Hydrolysis and superheated steam resistant
  • Very high stiffness
  • Very high creep resistant
  • High dimensional stability
  • Resistance against high energy radiation

Target industries:

  • Aircraft and aerospace technology
  • Food engineering
  • Food processing
  • Agricultural machinery
  • Aircraft and aerospace interior
  • Automotive industry
  • Electrical engineering
  • Chemical plant engineering
  • Mechanical engineering
  • Conveyor technology
